新款寬幅650mm石墨壓延機

用途Usage：把石墨膜壓延到適當厚度與底膜貼合到**起形成卷材，表面無裂痕、無壓痕、無損傷。

To press the graphite sheet to suitable thickness and to laminating graphite with back film and finially make it in roll shape. No cracks, no indentation and no damage on the material surface.

規格Specification：1.軋制精度誤差roll precision tolerance：≤±0.002mm2.設備線速度machine speed：1-15m/min(速度可調adjustable)3.軋制有效寬度roll effective width：50-400mm4.軋輥間隙調整范圍Space between rolls：0-3mm（可調adjustable）5.軋輥規格roll size：?400x500mm6.軋輥精度roll precision：a.軋輥硬度roll hardness：HRC66-68，      單邊硬度層single side hardness〉20mm b.軋輥圓柱度roll cylindricity：±0.002mm c.軋輥光潔度roll finish：Ra0.02 um d.軋輥徑跳動roll movement tolerance：±0.002mm7.收放卷管芯尺寸I.D. of unwind and rewind tube：3＂8.設備整體尺寸machine size：約長4.8Mx寬2.2Mx高2M 設計亮點寬幅650mm石墨壓延機特點Features 1．主操作采用觸摸式操作介面，直觀明了，操作便捷。   Touch panel is cleat and easy for operation2．主機采用兩馬達分別控制兩根軋輥，動力穩定，旋轉順暢。Two motors control two rolls which makes power stable and rotation more smooth.3．電器部分采用德國西門子，運行穩定。Electrical parts are from Germany Siemens, more stable.4. 片材生產，采用自動化程序控制，前后間距±1mm。Sheet processed by full auto programmable control, separation distance ±1mm.5.主機兩側分別配備收卷和放卷機構，進行卷材生產。    Unwind part and rewind part are in the two sides of machines.6.配備美國進口液壓缸，精密液壓站，壓力調節，壓力穩定。Hydraulic cylinder is imported from UAS, high-precision hydraulic station, pressure is stalbe.7.配備收放料EPC糾偏裝置,使材料進入主機和出料時，在同**基準線上不偏移。EPC system for both unwind and rewind part, keep material straight.8. 主機軋輥采用特殊鋼材鍛打精加工而成，硬度，抗壓能力強。Main rolls are made of special steel, high hardness, high pressure tolerance.9. 整機可滿足多種工藝的生產方式，配備多種軋制方案，滿足客戶不同的出貨要求。Machine can meet the requirements of different technologies,we have different projects for different demands.

石墨壓延機專業定制customize：專注于功能性新材料工藝研發和設備研發，為新材料生產企業提供從實驗室到量產化生產的整體解決方案。It focuses on the research and development of functional new materials and equipment, and provides the overall solution for the production of new materials from laboratory to mass production.
